FreezeTec® Heating Cables
The ELEKTRA FreezeTec™ system is your ultimate safeguard against frozen pipes and valves during harsh winter conditions. Designed for both indoor and outdoor use, it prevents costly damage by automatically activating when temperatures drop. With its built-in thermostat, the system eliminates the need for separate controls, making installation effortless and hassle-free.
Application
ELEKTRA FreezeTec™ is ideal for protecting pipes and valves vulnerable to freezing temperatures. It is designed for use under the following conditions:
- Pipe external diameter: up to DN 50 mm
- Insulation thickness: between 10 mm and 20 mm
- Maximum pipe temperature: +70°C
- Minimum ambient temperature: -25°C
Key Features & Benefits
- Automatic Operation – Built-in thermostat eliminates the need for a separate control system
- Energy Efficient – Activates only when necessary, reducing energy consumption
- Easy Installation – Quick and simple setup, with no additional control required
- Reliable Performance – Ensures uninterrupted protection for pipes and valves
Technical Specifications
- Thermostat activation: +3°C
- Thermostat deactivation: +10°C
- Power output: 12 W/m
- Power supply: 230V, 50/60Hz
FreezeTec - What's in the Box?
Elektra FreezeTec
