FreezeTec® Heating Cables

ELEKTRA FreezeTec™ Heating Cables – Automatic Frost Protection for Pipes and Valves

The ELEKTRA FreezeTec™ system offers a reliable solution for preventing frost damage to pipes and valves during freezing conditions. Each unit comprises a heating cable with an integrated thermostat, enabling automatic operation without the need for a separate control system. This design ensures quick and straightforward installation, providing peace of mind for both indoor and outdoor applications.

Key Features:

• Integrated Thermostat: Activates the heating cable at +3°C and deactivates at +10°C, ensuring energy-efficient operation.
• Automatic Functionality: Eliminates the need for external controls, simplifying the system and reducing installation time.
• Easy Installation: Designed for quick setup, making it suitable for various applications without extensive technical expertise.

Technical Specifications:

• Power Output: 12 W/m
• Power Supply: 230V, 50/60Hz
• Thermostat Activation Temperature: +3°C
• Thermostat Deactivation Temperature: +10°C

Available Models:

Application Guidelines:

• Pipe Diameter: Suitable for pipes with an external diameter up to DN 50 mm.
• Insulation Thickness: Recommended insulation thickness between 10 mm and 20 mm.
• Maximum Pipe Temperature: The temperature of the protected pipe should not exceed +70°C.
• Minimum Ambient Temperature: System operates effectively down to -25°C.

The ELEKTRA FreezeTec™ system is an efficient and cost-effective solution for safeguarding water mains and valves against freezing temperatures, ensuring uninterrupted operation during the winter months.
